GoodWe ES Uniq Series (3-12kW) | Single-Phase Low-Voltage Hybrid Inverter for Residential
The latest single-phase low-voltage hybrid inverter from GoodWe, purpose-built for residential solar systems. It connects to 48 V low-voltage batteries across a range of brands, features a straightforward LCD touch display, runs near-silently (<30 dB) and switches to emergency backup in as little as 4 milliseconds.
Key Highlights
- Seamless backup switching <4 ms: Sub-cycle mode transfer keeps power steady, so computers and critical equipment never drop out.
- Three-in-one versatile port: Supports connection of a generator, smart loads, or an existing on-grid inverter.
- Parallel connection of up to 6 units: Up to six units in parallel in both on-grid and off-grid modes for output expansion.
- High efficiency, quiet running: DC oversizing up to 200%, 20 A input current per string and operation below 30 dB.
Technical Specifications
- Models: GW3000 / GW3600 / GW5000 / GW6000 / GW8000 / GW10K / GW12K-ES-C10
- Nominal Output Power: 3,000 W – 12,000 W (3 kW – 12 kW)
- Battery Voltage Range: 40 – 60 V (nominal 48 V; supports lithium and lead-acid batteries)
- Max. Battery Charge/Discharge Current: 70 A – 240 A (max. charging power 12,000 W)
- MPP Trackers: 1 / 2 MPPT (MPPT voltage range 60 – 550 V / max. 600 V)
- Max. Efficiency: 97.6% (battery to AC: 95.55%)
- Switching Time: < 4 ms (seamless switching)
- Communication & Display: Touch-screen LCD, RS485, CAN, WiFi + LAN + Bluetooth
- IP Rating & Mounting: IP66 | wall-mounted
- Dimensions & Weight: 560 x 415 x 204 mm (3-6 kW models, 14.5-15.5 kg) / 560 x 444.5 x 226 mm (8-12 kW models, 27-29 kg)
